CPCB50-YT
YEAWEY
YW84272090CPCB50-YT
| engine: | |
|---|---|
| Mast type: | |
| Lift height: | |
| Tires: | |
| Fork: | |
| Color: | |
| Availability: | |
| Quantity: | |
Efficient heat dissipation & continuous work
Boasting a 40% larger all-aluminum radiator and optimized airflow design, it maintains the engine at 85℃ even in 60℃ environments. It can work in steel mill high-temperature workshops. Enables 12-hour non-stop operation without overheating, ensuring uninterrupted production efficiency.
Durable mast & load stability
The high-strength alloy mast, forged integrally to minimize welds, offers 10°/12° tilt angles. At 6t load, deflection stays ≤3mm, preventing cargo sway. Perfect for factory heavy equipment handling and port container stacking, its stability cuts collision risks, boosting operational safety.
Low noise & comfort
The fully enclosed cab uses multi-layer soundproof cotton and seals, keeping idle noise ≤75dB (like normal conversation). Ideal for precision workshops or night work, it avoids disturbing environments. The suspension seat, with height adjustment, absorbs 60% vibration, easing long-operation fatigue.
Operating space & ergonomics
With a 12cm-wider foot area and 3-level adjustable steering wheel (15° range), its space is 15% larger than peers. Suits large operators for long shifts: legs move freely, no constraints when turning or stretching, reducing muscle strain from prolonged work.
![]() | ![]() | ![]() | ![]() |
| Specification | CPCB50 | |||
| 1 | Fuel model | Diesel | ||
| 2 | Load capacity | kg | 5000 | |
| 3 | Load center | mm | C | 600 |
| 4 | Lift height | mm | H3 | 3000 |
| 5 | Full free lift height | mm | H2 | 200 |
| 6 | Fork dimension | mm | L | 1220×150×55 |
| 7 | Mast tilting angle | Deg. | 6/12 | |
| 8 | Min.turning radius | mm | 3250 | |
| 9 | Groud clearance | mm | M1 | 200 |
| 10 | Overhead guard height | mm | H6 | 2450 |
| 11 | Front overhang | mm | X | 590 |
| 12 | Max travel speed | km/h | 29 | |
| 13 | Max lift speed | mm/s | 550 | |
| 14 | Max.traction power | KN | 54 | |
| 15 | Max. gradeability | % | 35 | |
| 16 | Total length with fork | mm | L1 | 4660 |
| 17 | Total length without fork | mm | L2 | 3440 |
| 18 | Total width | mm | B1 | 1995 |
| 19 | Mast extended height | mm | H4 | 4400 |
| 20 | Mast lowered height | mm | H1 | 2500 |
| 21 | Tyres Front | 8.25-15-14PR | ||
| 22 | Type Rear | 8.25-15-14PR | ||
| 23 | Wheelbase | mm | Y | 2250 |
| 24 | Tread front | mm | B10 | 1470 |
| 25 | Tread rear | mm | B11 | 1700 |
| 26 | Service weight | Kg | 7980 | |
| 27 | Battery | V/Ah | (12/80)x2 | |
| 28 | Engine model | XICHAI 4DF3 | ||
| 29 | Engine power | kw/r.p.m | 85 | |
| 30 | Transmission | Automatic | ||
| 31 | Work press | Mpa | 20 | |
| YEAWEY forklift meet all emission standards. | |||||||
| Item | Engine model | Origin | Fuel type | Truck model | Emission std | Transmissioin | Rated Power kw/rpm |
| 1 | Xinchai A498BPG | China | Diesel | 4.0-5.0t | China stgae II | China | 45/2500 |
| 2 | Xinchai CA4D35 | China | Diesel | 5.0t | China stgae III | China | 60/2200 |
| 3 | Xichai 6110 | China | Diesel | 5.0-10.0t | China stgae II | China | 85/2000 |
| 4 | ISUZU 6BG1 | Japan | Diesel | 5.0-10.0t | Euro stage II | China | 82.4/2000 |
| 5 | MITSUBISHI S6S | Japan | Diesel | 5.0t | Euro stage III | China | 52/2300 |
| 6 | MITSUBISHI S6S-T | Japan | Diesel | 5.0-10.0t | Euro stage III | 63.9/2300 | |
